X-HS M U Threaded rod hanger with nail

Configurator
Technical Data
Documents
Features & Applications
Related Products
22237.tif
22233.tif

Ceiling hanger for attaching threaded rod

  • Application: Suspended systems
  • Material: Carbon steel
  • For use with (tools): DX 351, DX 460, DX 5, DX 6
ultimate

Choose options

Rod Diameter
  • M6
  • M8
  • M10
Pack size
  • 100 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
From 527.00 ILS

Technical Data

Application
Suspended systems
Material
Carbon steel
For use with (tools)
DX 351, DX 460, DX 5, DX 6
Base materials
Concrete (soft), Concrete (tough), Steel
Approvals
LR
Corrosion protection
Galvanized zinc coated <20 µm
Environmental Conditions
Dry indoor
Length
36 mm
For use with (tools) (global)
DX 351, DX 460, DX 5, DX 6
Product Class
Ultimate

Documents

Technical information
Approval document
Operating Instruction
pdf X-HS, X-CC Data Sheet, English [ 1.6 MB ]
pdf Direct Fastening Technology Manual, English [ 6 MB ]
pdf Scheda tecnica X-HS, X-CC en, English [ 130 KB ]

Features & Applications

Features

  • Designed for extremely high productivity – up to 10 times quicker than drilling and with less vibration
  • The hanger (threaded rod) can be fitted before the fastener is driven
  • Optimum threaded rod adjustment (adjustment range 25 mm)
  • Ballistic point for optimum driving characteristics

Applications

  • Ceiling hanger for attaching threaded rod
  • Installing suspended components, e.g. ceiling frames or pipes, on hard concrete or steel
  • Fastening installation channels on roof beams and ceilings
  • Securing flexible conduits, rigid conduits and cables to ceilings, walls and floors

For approval or certificate information, please see individual items.
