MQA-B pipe clamp saddle

Configurator
Technical Data
Documents
Features & Applications
Related Products
14678.eps
14676.eps

Ultimate galvanized pipe clamp saddle – fire-tested according to ETA

  • Approvals: ETA
  • Product Class: Premium
  • Material composition: Nut: C4C - DIN EN 10263, Plate: S 235 JRG2 - DIN EN 10025, Plastic: PBT
premium

Choose options

Thread connection - M
  • M12
  • M16
Pack size
  • 50 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
From 820.00 ILS

Technical Data

Details
Technical illustrations
Approvals
ETA
Product Class
Premium
Material composition
Nut: C4C - DIN EN 10263, Plate: S 235 JRG2 - DIN EN 10025, Plastic: PBT
Surface finish
Indoor Coated - Electro galvanized
Environmental conditions
Dry indoor conditions (C1) Indoor with temporary condensation (C2)
For use with
MQ system

Documents

Approval document
Operating Instruction
pdf ETA_Modulare_Schienensysteme_V1.4_de, German [ 14.2 MB ]
pdf ETA-23-0103 Static Fire Saddle nuts, English [ 2 MB ]

Features & Applications

Features

  • Quick connection of threaded components to the open side of MQ strut channels
  • Easy installation and positioning within MQ strut channel openings
  • Single, compact part – for higher productivity and flexibility
  • Various thread sizes available

Applications

  • Fastening pipes and air ducts
  • Fastening cable trays and cable baskets
  • Recommended for use in dry, interior environments
  • Applications with fire requirements

For approval or certificate information, please see individual items.
