Electrical Connector S-BT-ER HL

Configurator
Technical Data
Documents
Features & Applications
Related Products
2D side view of Electrical connector S-BT-ER M10/15 SN 6 HL
Application picture with cordless drill driver SBT 6-22
Electrical connector
Electrical connector
Electrical connector

Threaded screw-in stud (Stainless Steel, Metric or Whitworth thread) for electrical connections on steel in highly corrosive environments

  • Point type: Blunt tip
  • Base materials: Steel
  • Minimum thickness of base material (steel): 6 mm
ultimate

Choose options

Pack size
  • 100 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
From 2,500.00 ILS

Technical Data

Point type
Blunt tip
Base materials
Steel
Minimum thickness of base material (steel)
6 mm
Corrosion protection
Stainless steel A4(316) or equivalent
Environmental conditions
Marine, offshore, petrochemical, power plants, etc.
Material
Duplex stainless steel (1.4462)
Tightening torque
16 Nm
Product Class
Ultimate

Documents

Technical information
Approval document
Sustainability Documentation
Operating Instruction
pdf S-BT-ER (HC) HL, S-BT-EF (HC) HL Data Sheet, English [ 2.8 MB ]
pdf S-BT Visual Inspection Catalogue, English [ 1.9 MB ]
pdf S-BT HL Threaded Studs Specification, English [ 19.3 MB ]

Features & Applications

Features

  • Ideal for equipotential bonding
  • Enhanced protection against static electricity
  • Enhanced safety – allows electrical current to flow through the stud and then discharges it properly into the base material
  • Suitable for use on most standard steel structures and pipes
  • Stainless steel material provides high corrosion resistance – suitable for use in most industries: marine, offshore, petrochemical and power plant applications

Applications

  • Functional bonding
  • Protective bonding
  • Terminal connection
  • Lightning protection
  • Bonding and earthing/grounding

For approval or certificate information, please see individual items.
