X-C P8 Wood pins
Premium single nail for fastening wood to concrete using powder-actuated tools
- Base materials: Concrete (soft)
- Minimum thickness of base material (concrete): 80 mm
- Corrosion protection: Galvanized zinc coated <20 µm
standard
Choose options
Fastener shank length
- 82 mm
- 97 mm
- 117 mm
Pack size
- 100 pc
Quantity
Packs
Total Pieces
1
Discounted net
From 743.00 ILS
Technical Data
Base materials
Concrete (soft)
Minimum thickness of base material (concrete)
80 mm
Corrosion protection
Galvanized zinc coated <20 µm
Environmental Conditions
Dry indoor
Material
Carbon steel
Fastener shank diameter
3.7 mm
Washer size
8 mm
Point type
Cut point
Approvals
ICC-ES
For use with (tools)
DX 5, DX 6
Product Class
Standard
Documents
Features & Applications
Features
- Extra long nail for fastening thick wood to concrete
- Suitable for fastening to concrete with a hardness of up to 6,000 psi
- A hard nail with solid shank for buckle-free fastening of thick wood to concrete
- Suitable for soft to medium-hard concrete (up to 45 N/mm² concrete strength)
Applications
- Fastening wood to concrete
- Fastening formwork boards to concrete
For approval or certificate information, please see individual items.
